CUT Espresso

IT’S EASY,

IT’S FAST!

Available from 105.000 €

Precision, productivity and ease of use

The CUT Espresso is the fastest way to bring AGIE CHARMILLES Wire EDM technology to your shop floor!

Powered by the proven CUT E 600, this special package, combines speed, repeatability and more than 600 integrated cutting technologies in a ready-to-deliver solution. Easy to operate, fast to set up and designed for a broad mix of jobs - from standard production to demanding geometries - the CUT Espresso puts precision wire EDM within reach, without the wait.

From setup to first cut, it is ready to perform from day one, no complexity, no delays. Just precision, job after job.

Configuration includes

.

CUT E 600 Swivel door

.

Wire guide Starter kit 0.25 mm

.

Turbo Tech

.

Delivery

.

Installation & commissioning

. CUT E 600 Swivel door . Wire guide Starter kit 0.25 mm . Turbo Tech . Delivery . Installation & commissioning

Add-ons:

Drop door version . Cooling unit . Big spool 25kg . Wire chopper

Highlights

  • Compact and robust design: precision in less footprint

    The rigid mechanical structure ensures high precision and also the possibility to load heavy parts, everything by minimising the footprint of the machine.

  • IPG Generator: high repeatability, low power consumption, reliable results

    The Swiss-developed and manufactured IPG Generator, delivers precisely controllable pulses with minimal energy consumption, for highly reproducible cutting results.

  • UNIQUA: easy and intuitive interface

    The HMI is flexible and easy to use, it adapts to the operator and not vice versa, ideal for operators with less experience.

  • Collision Protection and cleverly engineered: easy to operate, easy to maintain

    The integrated collision protection on the X, Y and Z axes protects the workpieces from damage and the machine is very easy to maintain, again a big advantage for less experienced operators.

  • Turbo Tech: speed for costs reduction

    Thanks to IPG-enabled Turbo Tech, cutting speed increases over 40%, allowing substantial per-part cost reductions while maintaining uncompromised part quality.

Turbo Tech is fast!

Standard

Turbo Tech

Accelerated footage

Benchmark Cut

Piece type
- Punch

Geometry features
- Consecutive Radius
- Sharp Edge

Material
- Steel 60 mm / 2.36 Inches

Trim Strategy
- Back and forth

Benchmark Cut Results

Competition machine
Brass wire

CUT E
VX wire

AC CUT Brass 0.20 mm

Wire type

11 / 3 µm

Tf / Tkm

0.32 µm

Ra

3:30 h

Time

CUT E
Brass wire

AC CUT VX 0.20 mm

Wire type

9 / 3.5 µm

Tf / Tkm

0.30 µm

Ra

1:48 h

Time

1:42 h

Time saving

+49%

faster

AC CUT Brass 0.20 mm

Wire type

9 / 3.5 µm

Tf / Tkm

0.30 µm

Ra

1:04 h

Time

2:26 h

Time saving

+69%

faster

Maximum performance with VX Wire

Turbo Tech is fast, make it even faster with AC CUT VX wire!

The CUT Espresso special package gives you the opportunity to purchase the AC CUT VX wire as part of a bundle at a special price. Combined with Turbo Tech, this wire will make your CUT E 600 extremely fast!

Available in two formats:

  • 4 boxes of 2x8 Kg spools

  • 4 boxes of 16 Kg spools

This irresistible price is available only as bundle with the purchase of a CUT Espresso package, don’t miss this opportunity.

Do you also need a solution for the CAD/CAM software?

For customers new to AGIE CHARMILLES machines, the CUT Espresso Package includes a CAD/CAM software bundle at a highly attractive price, with flexible options to suit your needs.

Machine technical specification

CUT E 600

AXES

X, Y, Z Travel

600 × 400 × 350

mm

U, V Travel

±50

mm

Taper angle/height

±30/50

°/mm

X, Y, U, V, Z movement resolution

0,1

µm

Speed of axis movement (X, Y, Z)

0-3

m/min

Anti-collision protection for axes

X, Y, Z

Get your CUT Espresso today, this Special Package is available in limited quantities for a limited period.

Fill in the form below to get contacted by our Sales Engineers and secure your machine today.
